What is push pull connector

What is push pull connector

A push pull connector is a type of electrical connector commonly used in various industries for reliable and secure connections.  These connectors are designed with a unique locking mechanism that allows the user to "push" the connector into place and "pull" it out, which ensures a firm and secure connection during use.  The design of a push pull connector typically features a sleeve or collar that locks in place once the connector is inserted, preventing accidental disconnections even in harsh or high-vibration environments.

One of the main advantages of push pull connectors is their ability to provide a quick and secure connection with minimal effort.  This feature makes them ideal for applications where frequent plugging and unplugging are required, such as in audio, video, and telecommunications equipment, as well as in medical devices, industrial machinery, and aerospace systems.  The push-pull locking mechanism is designed to be simple yet effective, often requiring just a slight push to lock the connector in place and a simple pull to release it.

Get A Quote
Features

Why Choose SMARTNOBLE?

Rich options of military standard products or parts for land,naval and aviation.

Strong technical support from our engineer’s team.

Well experience in the key projects with fast delivery.

Competitive price and better performance

about SMARTNOBLE

We Have The Best Solutions for Your Business

Smartnoble Connectors provides research and development, production and sales of high-precision connectors. At present, the main products include more than 50 series and more than 5000 pieces of environment-resistant quick-plug electrical connectors, high-reliability power connectors, filter connectors, MII-C-38999 series high-density electrical connectors, push-pull electrical connectors, etc. Variety. Products are widely used in communications, aerospace, aviation, navigation, medical, transportation, electric power, new energy, instrumentation and other fields. Since its establishment, Smartnoble factory has passed lSO9001 quality management certification, military product quality management system certification, TS16949 quality management system certification, confidentiality qualification, CE certification, and some products have obtained a number of national patents. The company has a strong R & D team, advanced processing equipment, sophisticated testing equipment, short development cycle, short delivery cycle, short development cycle, excellent variety, strong service awareness, and has won unanimous praise from domestic and foreign customers.



Read More
User Reviews

What users say about SMARTNOBLE

Smartnoble products are not only high quality also stable, such fire suppression system for tanks and armored vehicles.

Mindray

Top quality in the movable and foldable 3.7meters Satcom antenna.

Cindy

Smartnoble has the best price performance in the reconnaissance drone, VTOL (vertical takeoff and landing) is convenient to operate with controller and little space limit of takeoff.

Vims

A very pleasant cooperation with great strength.

Michael
Frequently Asked Question

Do you have any question?

Push pull connectors are made from durable materials like stainless steel, brass, or high-grade plastics. These materials are selected based on the application, ensuring resistance to corrosion, wear, and harsh environmental conditions. For instance, medical applications may require biocompatible materials, while industrial uses may demand rugged metals.

Yes, many push pull connectors are designed to be waterproof with IP-rated seals, such as IP67 or IP68. This ensures they can withstand exposure to moisture, water, and dust, making them suitable for outdoor, medical, or marine applications where environmental protection is essential.

To select the right push-pull connector, consider factors like the number of pins, current rating, operating environment, and material compatibility. Also, evaluate whether features like waterproofing, EMI shielding, or miniaturization are required for your specific industry or project.

Yes, push pull connectors can handle high-frequency signals with minimal signal loss. Many are designed with shielding to reduce electromagnetic interference (EMI), making them suitable for data transmission in telecommunications, medical imaging, and other high-frequency applications.
